SCI-EVO-10200 series off-grid inverter. It generates electricity through solar panels and supplies it directly to the load. The excess is stored in the batteries. The inverter features dual PV input and dual AC outputs and adopted a newly designed LCD display. The perfect solution to provide off-grid, back-up power for homes and small business.
AN-SCI-EVO Series Solar Inverter AN-SCI-EVO10200 Specification
Model
SCI-EVO-10200
Rated Power
10200W
Maximum PV Input Power
10800W
Dimension: D x W x H (mm)
530*390*130mm
Net Weight (kgs)
14.5kg
Grid-Tied Operation
Number of MPPT Trackers/Maximum Input Current
2/18A
Output Voltage Range
195.5-253VAC
Nominal DC Voltage/Maximum DC Voltage
360VDC/500VDC
Start-up Voltage/Initial Feeding Voltage
90VDC/120VDC
MPPT Voltage Range
90-450VDC
Off-Grid Operation
Surge Power
20400W
AC Start-up Voltage/Auto Restart Voltage
120-140VAC/180VAC
Acceptable Input Voltage Range
90-280VAC / 170-280VAC
Nominal Operating Frequency
50/60Hz
Advantages of AN-SCI-EVO Series Solar Inverter AN-SCI-EVO10200
Off Grid Hybrid Inverter
Dual PV inputs & dual AC outputs.
Pure sine wave solar inverter.
High PV input voltage range(90-450VDC).
Inverter Running Without Battery
Built-in lithium battery automatic activation.
Bulit-in MPPT solar controller.
Built-in anti-dusk kit for harsh environment.
Smart battery charge design to optimize battery life.
RGB Indicator Light
Different colors indicate different working states, which can monitor the operation status.
WIFI Communication
WIFI available for IOS and Android.
ANERN AN-SCI-EVO Series Solar Inverter Factory
Anern has a professional automated factory and introduces advanced automated production equipment. All of our off grid hybrid inverters have passed ISO9001, CE, ROHS, TUV, and other certifications, and the quality meets international standards. As one of the leading hybrid solar inverter suppliers in China, Anern has a professional R&D team to customize exclusive solar energy solutions for each customer.
