Common Issues with Solar LED Street Light All-in-one

Solar LED Street Light All-in-one: Not Lighting Up


Possible causes


Incorrect wiring, light source failure, water ingress causing controller short circuit, prolonged rainy days, etc.


Solutions


First, check the controller of the solar LED street light all-in-one. Check the markings on it and verify if the corresponding lines are correctly connected. Then, check if there are water traces or rust on the controller's terminals. If there is, the controller might be damaged. If not, measure the battery voltage. For a 12V system, if the battery voltage is below 10.7V, the battery is no longer usable and needs to be replaced. On sunny days, check if the solar panels have current and voltage output. If they do, the solar panels are normal; otherwise, they are damaged. If none of these issues exist, the problem might be with the LED light source. Connect the light source to another power source to check if it light up. If it doesn't, replace the light source. If the solar LED street light all-in-one does not light up after several consecutive rainy days, it is normal because the solar panels were not generating electricity, and the stored power in the battery is depleted. When the sun returns, the solar panels will recharge the battery, and the solar LED street light all-in-one will resume normal operation.


Solar LED Street Light All-in-one: Light Source Flickering


Possible causes


Wiring issues, battery low on power.


Solutions


First, check if the wiring is correct and all connections and coverings are normal. You can also rewire everything. If the light source still flickers, consider checking the battery for low power. Measure the open-circuit voltage of the battery using a DC voltmeter. If the voltage is below 12V, the battery is low on power. Correctly connect the positive and negative terminals of the battery to the solar panels and charge for 1-2 days for the system to work normally.


Solar LED Street Light All-in-one: Light On for Short Time, Does Not Light Up on Rainy Days


Possible cause


insufficient battery capacity.


Solutions


If newly installed, the manufacturer-provided battery capacity might be falsely labeled and cannot meet the lighting requirements for consecutive rainy days. If the solar LED street light all-in-one has been used for several years, the battery might have degraded to the end of its service life and needs to be replaced.


Solar LED Street Light All-in-one: Light Source Not Fully Illuminating


The commonly used solar LED street light all-in-one LED light sources on the market are mostly dotted arrays. If some parts are lit while others are not, it suggests poor quality or inconsistent specifications of the LED beads, causing them to not work simultaneously under the same voltage and current. There could also be poor welding during assembly, resulting in poor contact of some beads. In this situation, replacing the LED light source should fix the issue and the solar LED street light all-in-one will illuminate normally.
